How to Measure Pallet Rack Beams and Uprights

Why It Matters

A beam an inch off will not seat. A frame of the wrong depth will not line up. Ten minutes with a tape saves a wasted delivery.

Measuring an Upright

1. HeightFloor to the top of the column.
2. DepthFront of the front column to back of the back column. Common depths are 36”, 42” and 48”.
3. Column sizeFace width and depth, such as 3” × 3”.
4. Hole patternTeardrop holes look like an upside-down drop. Take a clear photo with a tape in it.

Measuring a Beam

1. LengthThe clear opening between the two uprights, not the full steel length. That is the beam size.
2. Face heightFront of the beam, top to bottom.
3. StepThe ledge on the inside top edge for decking, if any.

Find the Maker

Look for a name, logo or sticker on the upright or beam end. If none, send two photos: the column face showing the holes, and the beam connector from the side showing the pins.

Count What You Have

Adding on: the bays and levels you want. Selling: uprights, beams and wire decks. Round numbers are fine.

Send It Over

Text or email sizes and photos. Contact us or browse used beams and used uprights.
